Beware that this venue data has not been confirmed for more than a year

Venuekeyboard_arrow_up

Venue or place nameLe 106
Room nameGrande Salle
CityROUEN
Postal code76100
AddressAllée François Mitterrand
Google map link
Phone+33 232 10 88 60
Websitehttp://www.le106.com/

Technicians Contactskeyboard_arrow_down

Technical Director / Manager NameGregory.PRUVOT
EmailGregory.PRUVOT@le106.com
Names of other technical contactsNicolas Nacry n.nacry@106.com

Accesskeyboard_arrow_down

Truck
Address / unloading dock info, freight elevator (size) (English)Cour technique privative de 700m² (accès par cadenas à code)
- Rampe d’accès Poids lourd 44t, hauteur max 4m15
Passage décor : 3m50 (L), 2m60 (H)
- Quai de déchargement : 47m², couvert, hauteur de
déchargement 1m, accès semi-remorque max 4m15 (H)
Bus Tour
Power plugs available for the bus:
CEE P17 32A2
Artists

Power Availablekeyboard_arrow_down

Electrical cabinet 1
Sound/Light/Video/Accessory Name Number Total power Transformer Position (stage) Position Distance to stage
Son
Connector Qty Phases Amp Diff Notes
CEE P17 32A 2 Tetra 32
CEE P17 32A 2 Mono 32
Electrical cabinet 2
Sound/Light/Video/Accessory Name Number Total power Transformer Position (stage) Position Distance to stage
Light
Connector Qty Phases Amp Diff Notes
PowerLock 1 Tetra
4 43kW
18 22Kw

Room / Gaugeskeyboard_arrow_down

F30
G20
Additional Information (English)Moyen d’accès et de manutentions (nacelle élévatrice verticale,
- gerbeur, transpalette, échelles…
Configurations
Configuration name Seating places Standing room PRM Total
80 318 398

Stagekeyboard_arrow_down

Hunder grill6
Lwall to wall15
Lproscenium arch12
P9
D1.2
Practicables25 praticables noirs (2m x 1m), communs aux deux salles
Hauteur de 0m40 à 0m80
Kits roulettes freinées
Legs drops1 rideau fond de scène noir mat sur patience manuelle, ouverture centrale
- 4 jeux de pendrillons :
Largeur : 2m.
Longueur : 8m
- Montage sur rail de roulement
OtherStructure sde la Scène: praticables noirs
arrière scène : 95m²

Soundkeyboard_arrow_down

Sound system availableyes
PA Sound SystemEnceintes suspendues : ADAMSON SPEKTRIX (par coté, 6 Spektrix + 2 Waves + 2 Spek Sub )
Infra basses sol : ADAMSON MD3-3 (x4).
Enceintes front fill : ADAMSON P8P (x4)
Amplification à contrôle numérique : LAB GRUPPEN PLM 10000Q
Convertisseur / distributeur / Processeur Lake LM26
Console PA and controlDIGICO SD8 avec surface de contrôle + rack de scène, 48 entrées micro, 8 sorties ligne, 8 sorties AES/EBU
- Interface MADI :
Carte RME HDSPe MADI/PMCIA
Monitor console and otherDIGICO SD8 avec surface de contrôle + rack de scène, 48 entrées micro, 16 sorties analogiques, 8 sorties AES/EBU
Monitor SpeakersEnceintes monitoring : D&B MAX (x13)
Side Fill : D&B 1 Qsub + 1 M4 par coté
Drums fill : D&B Qsub (x1)
14 canaux d’amplifications : D&B D12
Microphones- Kit microphones (commun aux deux salles) :
Dynamiques : 8 SM58 / 10 SM57 / 3 Beta56 / 2 Beta52 / 2 Beta57A / 1 Beta58A / 2 e906 / 4 e604 / 1
M88TG / 4 MD421 / 4 e604
Statiques : 2 OM7 / 2 OM5 / 1 D6 / 6 ATM350 / 2 Beta87A / 2 C535EB / 1 Beta91 / 2 Beta98H-C / 2 C414BXLS / 2 AE3000 / 2
AT4041 / 3 SM81LC / 4 KM184 / 2 SM87A
HF : 6 ULX-P4 / 3 ULX2-58 / 1 ULX2-B27A / 2 ULX-P4 / 2 ULX1 (émetteurs ceinture)
D.I : 13 AR133
Other equipmentRégulateur sonore de pression : AMIX SNA50-2R
- Patch de scène 48 lignes
4 départs sous patch
8 boitiers 24 lignes

Lightkeyboard_arrow_down

Console- MA LIGHTING, grandMA2 light ou grandMA2 ultra-light
- Convertisseur DMX/USB EMMTEC
Gradateurs numériques mobiles :
AVOLITE, ART2000 Powercube (x4)
R. JULIA, Digitour, 6x3kW (x2)
Automated lightMARTIN Mac Quantum Profile (x12)
AYRTON Nandobeam S6 (x12)
LED I-PIX BB4 Wash light (x6)
Rampe d’ACL STUDIO DUE CS4 (x5)
Rampe de 10 MR16 230V/75W pilotage DMX512 (x10)
Générateur de brume MDG Atmoshère (x1)
Stroboscopes MARTIN Atomic 3000 DMX (x2)
Tradges traditionnels :
R. JULIA, PC 310H 1000W/2000W (x20)
R. JULIA, Découpes 714 SX2 15/40° 2kW G22 (x9)
DTS, PAR 64 CP61 et 62 (x24)
FL1300 (x12)
Other equipmentRépartiteurs, amplificateurs de signaux DMX
4 x node ELC dmxLAN 6x
1 émetteurs DMX sans fil : ZERO 88, Zero Wire DMX
4 récepteurs DMX sans fil : ZERO 88, Zero Wire DMX
Grill plot

Videokeyboard_arrow_down

Ecran blanc mat type polichinelle, motorisé, monté sur chariots de roulement
Dimension 10m x 7m.
----------SYSTÈME MOBILE COMMUN AUX DEUX SALLES ----------
- Système mobile commun aux deux salles :
1 écran toile blanche mate + toile rétroprojection, dimension 4m x 3m
1 écran toile blanche mate, + toile rétroprojection, dimension 3m x 2m
2 projecteurs PANASONIC PT-DW 6300E (DLP, 1280x800, 6000 lumens)
1 projecteurs 2600 lumens SANYO ultra grand angle

Dressing room, Office, Cateringkeyboard_arrow_down

Dressing rooms
How many showers available4
Number Note, position Size Shower WC Sink WiFi
4 loges de 25m² à 17m² 4
Production office
Number Note, position Size WiFi Rj45 Direct line Furniture
oui
Catering
Notes, flight case size to access (English)1 salle de restaurant de 65m²
- 1 cuisine équipée.
- 1 laverie
How many plugs:
Utility room
If the room is empty:

Official Documents

Description Added
Dossier technique 2019-11-04
